The purpose of a Helical Pile is to transfer the load of a structure to competent soils.
The image below is a Heli-Pile® Helical Pile as it may appear supporting a new foundation grade beam
or column base. This figure depicts a double helix lead or starter section, a conventional extention,
a Heli-Pile® Terminator Extension Shaft and a new construction load transfer cap.
The load transfer cap is embedded in the concrete foundation.
